Beschreibung
Produktbeschreibung
- Billet compressor wheel with extended tip technology for the ultimate in aerodynamics
- Inconel 713 turbine wheel for high-temperature operation
- STD and T51R MOD in option for Compressor Cover with Speed Sensor Port integrated
- Billet Compressor Wheels with Extended Tip Technology
- HP Rating 750 – 1550
Additional information
- Compressor Wheel: 88x116mm 7+7 blade
- Compressor Inlet: 5.5 inch Slip-Fit
- Conpressor Outlet: V-Band
- Compressor Housing: T51R Mod
- Turbine Wheel: 96x88mm 9+0
- A/R: 1.45
- Turbine Housing Inlet: T6 Divided
- Turbine Housing Outlet: Marmon V-band
- -12AN Oil Drain Flange and TRB. Inlet Gasket Come in Box
